• Connects seamlessly with JioRouter
• Expand Wi-Fi Coverage
• Reduces network dark zones
• Enhances streaming experience
• Simple plug-and-play installation
Click Here to watch the Installation video
Key Features
Connect seamlessly to JioFiber Home Gateway
Technical Specifications
| Storage Temperature | -20 – 85 °C |
| Input Voltage | 12V/1A DC IN |
| Product Dimensions | 110mm x 110mm x 32mm |
| Ambient Humidity | 10% – 90% relative humidity |
| LAN-WAN Interface | 1*RJ45 Fast Ethernet Port |
| Backhaul Type | Wired and Wireless |
| Wi-Fi Frequency | 2.4GHz and 5GHz dual-band concurrent |
| Wi-Fi Standard | IEEE 802.11b/g/n and 802.11a/ac |
| Wi-Fi Antennas | Internal Antennas |
| Wi-Fi Mesh Standard | Wi-Fi Alliance EasyMesh |
| Wi-Fi Data Rate (maximum) | 2.4GHz: 300Mbps (40MHz), 2T2R MIMO; 5GHz: 867Mbps (80MHz), 2T2R MIMO |
Shipping & Delivery
Standard Delivery:-
The product will be delivered within 3-5 business days, currently, it may take a longer time.
For returns, the brand policy will apply. Please refer to our Returns Policy. Click here.
Offer & Information
Warranty Period:-
1-year manufacturer’s warranty
6 months power adapter warranty
Guidelines for placement of JioExtender
• Place the JioExtender on a table about three to four feet in height from the ground. Do not place it in corners
• Do not place JioExtender close to the floor, too high up, very close to the home ceiling or under low roof conditions
• Do not place the JioExtender in cabinets, closed areas, and cramped places along with other wireless or electrical devices
• Avoid placing JioExtender in between corridors connecting living rooms and bedrooms
• Maintain the line of sight between the JioFiber router and JioExtender to minimize obstacles between them
• Don’t put JioExtender beside any metal objects, such as home appliances, metal doors, etc.
• JioExtender has LED indicators to assist your placement decision. Please ensure the LED indicator is always Green.
